Zoom Compact Binoculars

  • 7-21x22
  • 7-21x22
  • 7-21x22
  • 7-21x22
  • 7-21x22
  • 7-21x22
  • 7-21x22
7-21x227-21x227-21x227-21x227-21x227-21x227-21x22

7-21x22

  • Model:BTZ5563
  • Magnification: 7-21x
  • Objective Lens: 22 mm
  • Angle of View: 5.5˚- 3.5°
  • Product description: 7-21x22 Zoom Binoculars from deliver versatility and portability that easily fits in a pack, pocket, or purse.
  • INQUIRY

Key Features :
● BK7 Reverse-Porro Prisms
● Compact Reverse Porro Prism Design
● Fully Multi-Coated Optics
● Exceptionally Wide Zoom Range
● Fold-Down Rubber Eyecups
● Center Focus Knob
Overview :
7-21x22  Zoom Binoculars from  deliver versatility and portability that easily fits in a pack, pocket, or purse. The wide 3x magnification range is well suited for medium- to long-range viewing and ideal for sightseeing and glassing on the trail or in the woods.   proprietary zoom lever, lLocated laterally to the right eyepiece, is ergonomically placed to be accessible with either hand for easier use.   Fold-Down eyecups help to ensure a comfortable viewing distance for almost any viewer—even if they wear eyeglasses.
Optical Performance:
● Wide 7-21x zoom range
● 22 mm objective lenses
● Compact reverse-Porro prism design
● Multi-Coated  optics ensure images are bright and clear with improved contrast and accurate color representation ● Wide 38°- 74°  apparent angle of view
● 294 (7x) to 189 (21x) foot field of view at 1000 yards
Use and Handling :
● Large center focusing wheel is easy to manipulate, even when wearing gloves
● Right-eye dioptric correction enables users to compensate for individual optical prescription ● Fold-Down  rubber eyecups for comfortable use with or without eyewear
● Close 5' short-focus distance
● 3.1 - 1.0 mm exit pupil
● 13.0-10 mm eye relief
Construction Details
● Lightweight plastic chassis
● Protective black rubber armor provides a slip-resistant grip
● Textured palm pads improve grip security
● Weight: 245 g
Performance :

Model BTZ5563
Specification 7-21x22mm
Magnification 7x - 21x
Objective Lens Diameter 22 mm
Angle of View 5.5˚- 3.5°
Field of View 98 - 63m @ 1000 m
Field of View 294 -189ft @1000 yd
Minimum Focus Distance 16.40 ft  / 5 m
Exit Pupil 3.1 - 1.0   mm
Eye Relief 13 - 10 mm
Diopter Adjustment Yes / ±4
Focus Type Center
Prism Type Porro (BK7)
Lens Coating Fully Multi
Eyecups Fold-Down
Weight 245 g
Size 114x53x102 mm
